Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test

Name: Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test
Brand: MM-TECH
Price: 750 USD

China Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test factory

Brand Name : MM-TECH

Model Number : SWT-NS003

Certification : CE

Place of Origin : HEBEI, CHINA

MOQ : 1

Price : US$750 - 900 /SET

Payment Terms : T/T, Western Union, PayPal

Supply Ability : 9,000 sets / per month

Delivery Time : Within 7 days

Packaging Details : 1 Alloy Box and 1 Carton

Model : SWT-NS003

Dielectric strength : 1500V/50HZ 1min no breakdown

Thermo protector : Anto reset 130±5°C

Shape : Hemispherical

Max.air volume : ≤30L/min

Noise : ≤48dB(A)

Frequency : 50/60Hz

Testing size : 700cm2

Max. vacuum : -84Kpa

Temperature for using : 5-40°C

Isullation : B class

Voltage : 230V

Contact Now

Testing Vacuum Air Leak Tester for Waterproofing Membrane Weld Test Tool

Vaccum Leak Test Tester Presentation:

Vaccum leak tester is designed as CJJ113-2007 standard from National construction department,which is small body and strong negative pressure.The vaccum part is of blow moulding acrylic.The whole vaccum is clean and strong resistant,connected with special strip seal.It is used in disposal landfill project and roof waterproofing check.

Vaccum Leak Test Tester Technical Data:

Voltage:	230V
Frequency:	50/60HZ
Max. negative pressure:	84kpa
Normal testing negative pressure:	20-40kpa
Effective leak testing size:	Φ280mm
Size of the vaccum:	Φ360mm
Connecting way bewteen vaccum and pump:	quick connector
Weight:	5.8kgs
Shape:	Hemispherical

Precautions:

(1)Test pin should be properly and cleanly kept . Shall handled carefully to avoid damage.

(2)Generally the pressure of needle is appropriate at 3/ 4 of cap , not necessary full . The instrument should be checked regularly to ensure the accuracy..

Construction of the scene:

Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test

Exhibition:

Hemispherical Vacuum Air Leak Tester For Waterproofing Membrane Test

Service:

24 months. -- If any parts broken or doesn't work under normal operating, we will provide them for free.
